1、Intel® Core™ i7/i5/i3/Celeron® Processor SoC

2、DDR4 1866/2133, SODIMM x 1

3、DVI, DP, 18/24-bit Dual-Channel LVDS

4、2 CH Audio

5、SATA 6.0 Gb/s x 1 & mSATA (Shared with Half-size Mini-Card and Selected by BIOS)

6、Supports 8-bit Digital I/O, USB 2.0 x 2 , USB 3.0 x 4

7、COM x 4 (RS-232 x 1, RS-232/422/485 x 3)

8、Mini-Card Slot x 1 (Full size), TPM, SIM

9、Wide DC Support 9~36V, +12V Only (Optional)

10、4/5/8-wire Resistive Touch Screen Controller

11、BIO Connector for Daughter Board

12、Solder Design for System Assembly and Thermal
